| 參數 Parameter |
ANY-TWM-4 | ANY-TWM-8 | ANY-TWM-12 | ANY-TWM-24 | ANY-TWM-48 |
| 通道數 Number Of Channels |
4道 | 8道 | 12道 | 24道 | 48道 |
| 適用劑型 Applicable Dosage Form |
各種規格圓片、橢圓片、00#～5#膠囊 | ||||
| 顯示刻度 Display Scale |
0.1mg | ||||
| 稱量範圍 Weighing Range |
20mg-2000mg | ||||
| 檢測精度 Check The Accuracy |
±1mg | ||||
| 檢測速度 Detection Speed |
3.36 萬粒/h |
6.72 萬粒/h |
10.08 萬粒/h |
18.72 萬粒/h |
37.44 萬粒/h |
| 操作屏 Operation Screen |
觸屏(18.5英寸) | ||||
| 功 率 Power |
3kW | 3kW | 3kW | 4kW | 5kW |
| 周圍環境 Surrounding Environment |
溫度：10~30°C、濕度：30~70% | ||||
| 外形（mm） Shape (mm) |
980*800 *1700 |
980*800 *1700 |
980*800 *1700 |
1210*800 *1700 |
1400*1000 *1700 |
| 重量（kg） Weight (kg) |
500 | 500 | 500 | 600 | 700 |
功能及特點
| 功能特點 | Features |
| 精密的稱重技術與人性化設計，100%的檢查從膠囊機生產出來的所有產品，並精準單通剔除重量不合格產品。 | It has precise weighing technology and humanized design, can 100% inspect all products produced from the capsule machine, and accurately reject products with nonconforming weight through single channel. |
| 更換極少零件即可適用不同規格型號的膠囊檢測，免工具更換，時間少於1分鐘。 | It can be used for detecting capsules of different specifications and models with replacement of very few parts, and the replacement takes less than 1 minute without tool. |
| 精簡結構排列、專利轉輪取囊技術，無損傷檢測，任何一環節都無需人工，降低人為風險。 | Simplified structure arrangement and patented runner capsule extraction technology realize nondestructive testing, and no labor is required in any step, reducing human risk. |
| 自適應濾波技術、零點追蹤、動態補償軟件算法，摒除地面震動、風口氣流等環境干擾。 | Adaptive filtering technology, zero-point tracking, and dynamic compensation software algorithm eliminate environmental interference such as ground vibration and air flow at air conditioner vents. |
| 模塊化設計，各種產能機型可選，能夠匹配各種型號的膠囊充填機。 | Modular design and various optional capacity models can match various types of capsule filling machines. |
| 專門定制稱重模塊，穩定時間小於0.1秒，綜合精度最高可達±1mg。 | The specially customized weighing module has the stabilization time less than 0.1 seconds and the comprehensive accuracy up to ± 1 mg. |
| 設備各個運行的動作均採用電機驅動，不需要消耗壓縮空氣，最大程度的減少了設備的振動和噪音，減少振動對稱重傳感器的影響。 | Each operation of the equipment is driven by a motor and does not need to consume compressed air, which minimizes the vibration and noise of the equipment and reduces the impact of vibration on the load cell. |
| 檢測數據實時存儲，能夠存儲10年以上的稱量數據。 | Real-time storage of detection data, capable of storing weighing data for over 10 years. |
| 過載保護功能防止無意觸碰而損壞稱重傳感器。 | Overload protection prevents unintentional touch from damaging the load cell. |
| 砝碼校準時間少於3分鐘。 | The weight calibration time is less than 3 minutes. |
| 過程中全自動零點校正。 | Fully automatic zero-point calibration during the process. |
