| 型號 | Model | ANY-JZ-II(膠囊) / ANY-PZ-II(片劑) |
| 稱重方式 | Weighing method | 膠囊/片劑在線抽樣單粒稱重 Capsule / tablet online sampling and single weighing |
| 稱量速度 | Weighing speed | 20-30粒/分鐘 20-30 capsules / min |
| 稱量範圍 | Weighing Range | 0.001g-200g |
| 稱量周期 | Weighing cycle | 1-2分鐘 1-2min |
| 適用範圍 | Scope of application 膠囊 Capsules | 000#、00#、00#加長、0#、0#加長、1#、2#、3#、4#、5# |
| 適用範圍 | Scope of application 片劑 tablets | 不同形狀的片劑 Tablets of different shapes |
| 稱量精度 | Quantity precision | ±1mg |
| 壓縮氣壓 | Compressed air pressure | ≥0.5MPa |
| 外形尺寸(mm) | Overall dimension(mm) | 715*695*1225 |
技術比較
| 傳統膠囊/片劑生產 Traditional capsule/tablet production |
在線抽檢、調整裝置(選配)連續生產 Online sampling, adjustment of loading capacity (optional) for connection production |
| 人工抽檢 Manual sampling |
自動化智能抽檢 Automated intelligent sampling |
| 每10-20分鐘一次 Once every 10-20 minutes |
每1-2分鐘一次，頻次多，提升產品質量穩定性，風險降到最低 Once every 1-2 minutes. High frequency improves the product quality stability and minimize the risk. |
| 人工書寫相關數據 Manually writing relevant data |
自動打印、自動存儲相關數據記錄，QA人員可直接通過電子數據判斷 It can automatically print and store relevant data records, and QA personnel can directly judge through electronic data. |
| 數據可塗抹更改 Data cannot be changed or falsified |
數據不可更改作假 No contact, no contamination |
| 人跟產品有接觸，易污染產品 People have contact with products and are easy to contaminate products. |
無接觸，無污染 No contact, no pollution |
| 出現偏差，需停機人工調整 When deviation occurs, shutdown is required for manual adjustment |
無需停機，自動根據檢測數據反饋調整(選配) Shutdown is not required, the equipment will automatically adjust according to detection data feedback (optional) |
功能及特點
| 功能特點 | Features |
| 自動抽取膠囊/片劑成品，自動排序、計數，單粒膠囊/片劑逐一稱量。 | It can automatically extract capsule/tablet products, automatically sort, count, and weigh capsule/tablet one by one. |
| 可設定稱量數量、理論值、內控上下限(報警)、廢品剔除上下限。 | The number of weighed products, the theoretical value, the upper and lower limits of the internal control (alarm), and the upper and lower limits of the rejects can be set. |
| 自動剔除超限膠囊/片劑，自動回收合格品，超限報警和控制停機。 | It can automatically eliminate out of limit capsules/tablets, automatically recover conforming products, give out-of-limit alarms, and control shutdown. |
| 稱量數據即時打印，歷史數據海量儲存。 | Instant printing of weighing data and mass storage of historical data. |
| 運用裝量偏差曲線進行趨勢分析。 | Use the load deviation curve for trend analysis. |
| 整個抽檢過程無需人工接觸膠囊/片劑，可實現抽檢過程無人化操作。 | The entire sampling process does not require manual contact with the capsule/tablet, realizing the unmanned operation of the sampling process. |
| 儀器設備可移動、可固定、可調水平，防氣流擾動、抗震動、防粉塵、易清潔。 | The instrument and equipment can be moved or fixed, can adjust the level, are resistant to airflow disturbance, vibration and dust, and are easy to clean. |
| 充填機、壓片機裝量自動調整，實現膠囊劑型/片劑型的完全自動化生產（選配）。 | The filling machine and tablet press are automatically adjusted to achieve fully automated production of capsules/tablets (optional). |
